*Nota: Las imágenes son de referencia. El tono, la beta y otros detalles del producto pueden presentar variaciones según el lote de fabricación.

Beam 100x52 Maple 2025

Name: Beam 100x52 Maple 2025
Brand: Cao Cao
SKU: 1185
Price: 928.00 MXN
Availability: InStock

Type: EXTERIOR WPC

SKU: 1185

$ 928.00

$ 928.00 ~~$ 928.00~~

Tax included. Shipping calculated at checkout.

Hurry up, only 4 items left in stock.

Our maple-colored outdoor beam is manufactured using co-extrusion technology, which combines a protective layer with a core composed of 60% wood resin and 40% high-density HDPE polymer.

This composition makes it highly resistant to extreme weather conditions, including intense sun, rain, snow, and high temperatures. Ideal for patios, gardens, pool areas, and other outdoor spaces.

Sold per piece. Measurements: 10 cm wide x 5.2 cm thick x 3 m long.

Why is it the best option?

Long-lasting, modern design, minimal maintenance, easy to clean, resistant to sun, rain, and other environmental factors.

Delivery time?

Shipping may take between 4 and 15 business days as, due to the size of the materials, it is considered an irregular load.

Price

Price per PIECE $800 + VAT. Prices subject to change, formal quotes are valid for 5 days.

Exterior WPC Beam - Exterior WPC Beam -

Exterior WPC Beam

Innovative and long-lasting solution

Discover the perfect outdoor solution at shopcaocao.com: our exclusive outdoor WPC Beam is a modern, resistant, and eco-friendly alternative for transforming any outdoor space.

Made from a high-quality blend of wood and plastic, this beam offers superior resistance to weathering, fading, insects, and moisture. Its non-slip surface and easy-to-clean finish make it the ideal choice for demanding climates and high-traffic areas.

In addition to being durable, it is an environmentally friendly option, made from recycled and recyclable materials, aligning with sustainable construction trends.

Its modern and elegant design is suitable for terraces, patios, gardens, pergolas, pool areas, and other outdoor spaces, providing an impeccable and functional visual finish.

installation - installation - installation -

Technical Installation Guide

Clear instructions for a perfect finish

Logra un acabado perfecto siguiendo nuestras instrucciones detalladas. A continuación, encontrarás una lista de los materiales necesarios para realizar la instalación de forma correcta y eficiente.

Flexómetro

U-brackets o L-brackets

Tornillos

Taladro

Sierra eléctrica

Step-by-step installation

Preparación del área y estructura subyacente

Antes de iniciar, asegúrate de que la estructura de soporte sea robusta y adecuada para recibir las vigas de WPC.

Limpia el área para eliminar polvo, suciedad y obstáculos que puedan interferir.

Medición y planificación

Utiliza una cinta métrica para medir el espacio disponible y definir la ubicación precisa de cada viga.

Marca claramente los puntos donde irán colocados los soportes (U o L-brackets).

Corte y ajuste de las vigas

Si las dimensiones del proyecto lo requieren, recorta las vigas con una sierra adecuada para WPC, asegurando cortes rectos y limpios.

Fijación con U o L-brackets

Coloca los soportes (U o L-brackets) en las posiciones marcadas.

Utiliza el taladro y tornillos para exteriores para fijarlos firmemente a la estructura subyacente.

Verifica que los brackets queden alineados correctamente.

Instalación de las vigas

Coloca las vigas en su lugar sobre los soportes, ajustándolas de manera que queden niveladas y en la posición correcta.

Fijación adicional (opcional)

Si el diseño o el entorno lo requiere, refuerza las vigas utilizando tornillos adicionales para asegurar una sujeción extra firme.

Acabado y revisión

Revisa que todas las vigas estén perfectamente niveladas, alineadas y bien fijadas.
Realiza ajustes finales para lograr un acabado estético y resistente.

Limpieza y detalles finales

Retira el polvo o residuos de la instalación.

Realiza una última inspección para asegurarte de que todo el sistema esté seguro y visualmente impecable.

Consejos adicionales

Mantén una separación uniforme entre vigas para lograr un diseño armonioso y una estructura funcional.

Elige adecuadamente entre U-brackets o L-brackets según las necesidades del proyecto (diseño y soporte).

Protege tu seguridad: usa guantes de trabajo, gafas de protección y ropa adecuada durante toda la instalación.

Planifica visualmente: Antes de fijar definitivamente, coloca las vigas "en seco" para asegurarte de que la distribución sea la ideal.

Technical Data Sheet

Panel Size

3m x 10cm x 5.2cm

Panel Length

3m (Adjustable, can be cut)

Panel width

10 cm

Panel thickness

2.05 inches

Presentation

Loose part

Recycling

Made from recycled materials

Lifespan

25 years residential use, 10 years commercial use

Maintenance

Minimal maintenance

Installation

The installation of the 100x52 CO-EXTRUDED WPC Beam requires special hardware.

Application

The 100x52 CO-EXTRUDED WPC Beam can be used both indoors and outdoors, recommended for facades, windows, doors, railings, terrace roofs, pergolas, balconies, and outdoor fences.

Composition

60% wood resin and 40% high-density HDPE polymer.

Weight

7.35 kg

Use

Interior and exterior

Accessories

Braket C

Es un herraje en forma de C que permite fijar y asegurar las vigas decorativas de exterior de forma discreta y resistente. Ideal para instalaciones en techo, muro o piso, con un acabado limpio y seguro.

Braket U

Es un herraje en forma de U diseñado para fijar de forma segura las vigas decorativas de exterior al techo, muro o piso. Aporta estabilidad y un acabado profesional.

Clips L

Es un soporte metálico en forma de L que facilita la sujeción lateral de vigas exteriores. Ideal para reforzar uniones y dar mayor firmeza a la instalación.

Tapones

Es un accesorio que cierra y cubre los extremos de las vigas de exterior. Brinda un acabado estético, limpio y protege las vigas del polvo y humedad.
